DC Charger
DC Charger (30kW) IP54
-
CCS-1 or CC2-2 / CHAdeMO / AC Type 1 or 2
-
Support OCPP1.6J
-
IP54, ~30°C~50°C ambient temperature full power charging
-
Wall mounted / Pole installation
-
Compatible with 30kw / 500V / 750V, optional 1000V output
-
Internal high precision AC energy meter
-
Full safety function with output contactor and fuse, SPD, RCD, leakage switch, insulator detector, software logic for mutli-protection
-
7" TFT touch screen LCD
-
Multiple charging termination methods: Auto charge, Time setting, Fee setting, Energy setting, SOC setting
-
Inner LAN / 3G / 4G wireless support, RFID authorization & Mobile App payment support (optional)
![Infypower_wall mount_blue(with socket)_edited.png](https://static.wixstatic.com/media/7bda61_462617daef10461cab3f4096a5e8bbc7~mv2.png/v1/crop/x_9,y_0,w_382,h_500,q_85,blur_2,enc_auto/7bda61_462617daef10461cab3f4096a5e8bbc7~mv2.png)
DC Charger (60kW) IP55
-
CCS1 or CCS2, CHAdeMO and GB/T configure support, optional AC Type 2 cable support
-
IP55 design with high protection and high reliability for harsh environment
-
Wall mounted, optional stand column installation
-
EMC Class B, TUV CE and UL certification
-
OCPP 1.6 J and DIN/ISO15118 support, OCPP 2.0 and ISO15118-20 support with the SW update
-
Power can transfer between the two charging cables and can output at the same time for the two charging cables
-
60kW charging capacity, charging voltage from 150V to 1000V
-
Optional 44kW V2G configuration, support CHAdeMO and CCS standard
-
User friendly interface with tempered glass protective 7" TFT capacitive touch screen LCD
-
Multiple charging modes: Auto basis,Time basis,Amount basis,Energy basis,SOC basis
-
Multiple power distribution modes: Standalone,Current switch,Plug switch,Full hold
-
Internal high precision AC energy meter and DC energy meter, optional VDE and PTB certification type
-
LAN and optional LTE wireless support, OTA support, RFID authorization and App payment support
![](https://static.wixstatic.com/media/7bda61_4c9c19d65456423c808207aef2fbd8b4~mv2.png/v1/crop/x_60,y_0,w_381,h_500,q_85,blur_2,enc_auto/7bda61_4c9c19d65456423c808207aef2fbd8b4~mv2.png)
DC Charger (60-120kW) IP54
-
CCS-1 or CC2-2 / CHAdeMO / AC Type 1 or 2
-
Slim version for small carparking bay
-
Customizable outlook design
-
Support OCPP 1.6J
-
Scalable power output rating up to 120kw
-
IP 54 design for both indoor and outdoor applications
-
Optional Ring loop power network function
-
Power transfer between the two DC guns
-
Type B residual current circuit breaker
-
Full safety function with input/output contactor, fuse, EPO, SPD, leakage switch, insulator detector, software logic for multi-protection
-
User friendly interface with 7” TFT touch screen
-
Multiple charging termination methods: Auto charge, Time setting, Fee setting, Energy setting, SOC setting
-
Internal high precision AC/DC energy meter
-
3G/4G wireless com support, RFID/NFC and Mobile App payment support (optional)
![](https://static.wixstatic.com/media/7bda61_48d4c974d4a842dcb50805dac5f17cbc~mv2.png/v1/crop/x_60,y_0,w_381,h_665,q_85,blur_2,enc_auto/7bda61_48d4c974d4a842dcb50805dac5f17cbc~mv2.png)
DC Charger (150kW) IP65
-
CCS-1 or CC2-2 / CHAdeMO / AC Type 1 or 2
-
Support OCPP 1.6J
-
Easily configure the output power from 120kw to 150kw, and the output voltage from 500 to 750V
-
IP 65 design with high protection and reliability for harsh environment
-
Power transfer between the two DC connectors, and also can output at the same time for the two DC connectors
-
Full Safety function with output contactor and fuse, EPO, SPD, leakage switch, insulator detector protection
-
User friendly interface with 7” TFT touch screen LCD
-
Multiple power distribution modes: Standalone, Current switch, Plug Switch, Full Hold, Master Slave
-
Internal high precision DC energy meter
-
LAN and optional LTE wireless support, RFID authorization and Mobile App payment support
![DC150kW-1_edited.png](https://static.wixstatic.com/media/7bda61_67975ee4a21d4272a550cb901e5d91f4~mv2.png/v1/crop/x_60,y_0,w_381,h_500,q_85,blur_2,enc_auto/7bda61_67975ee4a21d4272a550cb901e5d91f4~mv2.png)
DC Charger (180-240kW) IP55
-
CCS-1 or CC2-2 / CHAdeMO / AC Type 1 or 2
-
Support OCPP 1.6J
-
IP55 design with high protection and high reliability for harsh environment
-
Optional CoolRing function realize the power transfer between the two chargers which can get max 360kW in one Charger
-
Power can also transfer between the two DC connectors, and also can output at the same time for the two DC connectors
-
Easily configure the output power from 60kW to 180kW, and compatible with the voltage from 500V to 1000V
-
Full safety function with output contractor and fuse, EPO, SPD, RCD, leakage switch, insulation detector protection
-
User friendly interface with 7" TFT touch screen LCD
-
LAN and optional LTE wireless support, RFID authorization and Mobile App payment support
![](https://static.wixstatic.com/media/7bda61_f3f391f7dd484a849a30202934436bf6~mv2.png/v1/crop/x_60,y_0,w_381,h_500,q_85,blur_2,enc_auto/7bda61_f3f391f7dd484a849a30202934436bf6~mv2.png)
DC Charger
(Liquid/ Air cooling)
(480-640kW) IP65/54
-
CCS1 / CCS2 / CHAdeMO / GBT EV Charging standard support
-
IP65 for the dispenser and IP54 for the power cube with high protection and high reliability for harsh environment
-
Optional one CCS / GBT standard 500A liquid cooling charging connector support with Any Cooling™ liquid cooling solution
-
Optional 250A or 300A CCS normal charging connector for the balance of cost and charging capacity
-
OCPP 1.6J support and smart charge support
-
Max 4 charging dispensers with 8 charging connector configuration
-
CoolRing™ ring net power transfer between the dispensers' connectors to improve the charging operation efficiency
-
Easily configure the output power up to 480kW and the output voltage up to 1000V
-
Full safety function with output contactor and fuse, EPO, SPD, leakage protection switch, insulation detect protection
-
User friendly interface with tempered glass protective 7" TFT capacitive touch screen LCD
-
Internal high precision AC and DC energy meter, optional VDE and PTB certification type
![](https://static.wixstatic.com/media/7bda61_7e5883c55bfe49dd930f4f1307869b3a~mv2.png/v1/crop/x_22,y_0,w_275,h_501,q_85,blur_2,enc_auto/7bda61_7e5883c55bfe49dd930f4f1307869b3a~mv2.png)
![](https://static.wixstatic.com/media/7bda61_a5f7198762b84b36b85cd8ed69029845~mv2.png/v1/fill/w_69,h_40,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/7bda61_a5f7198762b84b36b85cd8ed69029845~mv2.png)
Battery Charger Solution
-
Total electric insolation between the grid, battery, EV, and new energy input
-
Full compatible between different system configuration
-
Flexible change the system configuration capacity and power direction
-
Differentiation battery group configuration and access
-
Unify EMS strategy
-
HPC 500A charging support
![](https://static.wixstatic.com/media/7bda61_9be1f7bd1ca6443e8872816a336a8963~mv2.png/v1/crop/x_251,y_0,w_381,h_400,q_85,blur_2,enc_auto/7bda61_9be1f7bd1ca6443e8872816a336a8963~mv2.png)
